This product was designed by Unexpected Maker.
By buying this product you support original hardware creators.
OMGS3 is the world’s smallest, fully-featured ESP32-S3 microcontroller board/module!
OMGS3 is the world’s smallest, fully-featured ESP32-S3 microcontroller module - just drop it on your PCB and focus on your features!
It can also be used without a carrier PCB if you want to solder wires directly to it, for those tiny little projects that need the smallest of boards!
Features & Specifications
| Processor | ESP32-S3-PICO · 32-bit · Dual-core LX7 · up to 240 MHz |
| Flash | 8 MB QSPI |
| PSRAM | 2 MB QSPI |
| GPIO | 17 |
| Wireless | Wi-Fi 4 2.4 GHz · 802.11b/g/n · BLE 5 + Mesh |
| USB | D+/D− pads for an external USB connector · USB Serial/JTAG support |
| Power | 700 mA · 3.3 V regulator |
| Battery | LiPo charging · optimised power path for low-power battery use |
| Fuel gauge | I²C · MAX17048G+T10 |
| Onboard | Ultra Low-power RGB LED |
| Antenna | 3D high-gain antenna |
| Connection | 1.27 mm pitch pads |
| Size | 25 × 10 mm |
Compare the modules.
EdgeS3[D], OMGS3, NanoS3 and TinyPICO Nano specifications
| EdgeS3[D] | OMGS3 | NanoS3 | TinyPICO Nano | |
|---|---|---|---|---|
| MCU | ESP32-S3-PICO | ESP32-S3-PICO | ESP32-S3FN8 | ESP32-PICO-D4 |
| Processor | Dual-core LX7 · up to 240 MHz | Dual-core LX7 · up to 240 MHz | Dual-core LX7 · up to 240 MHz | Dual-core LX6 · up to 240 MHz |
| Flash | 8 MB | 8 MB | 8 MB | 4 MB |
| PSRAM | 2 MB | 2 MB | 8 MB | 4 MB |
| Available IO | 29 + 8 | 17 | 27 | 27 |
| 2.4 GHz Wi-Fi | Wi-Fi 4 | Wi-Fi 4 | Wi-Fi 4 | Wi-Fi 4 |
| Bluetooth | BLE 5 + Mesh | BLE 5 + Mesh | BLE 5 + Mesh | Classic BT + BLE 4.2 |
| Zigbee / Thread | — | — | — | — |
| Format / connection | M.2 B-Key module | Surface-mount module | Surface-mount module | Surface-mount module |
| USB | Via carrier · USB OTG / JTAG | Via carrier · USB OTG / Serial / JTAG | Via carrier · USB OTG / Serial / JTAG | Via carrier · USB-to-serial |
| 3.3 V regulators | 1 × 700 mA | 1 × 700 mA | 1 × 700 mA | 1 × 700 mA |
| STEMMA QT | — | — | — | — |
| RGB LED | — | NeoPixel | NeoPixel | — |
| Antenna | Onboard + u.FL · software switch | Onboard | Onboard | Onboard |
| Battery | I²C fuel gauge + LiPo charging | I²C fuel gauge + LiPo charging | LiPo charging | LiPo charging |
| Size | 22 × 23 mm | 25 × 10 mm | 28 × 12.7 mm | 27 × 13 mm |
Getting Started Using Your OMGS3
Please have a read through our Getting Started Guide for information on how to start using your OMGS3 Development Board.
Code any way you like!
Ships with CircuitPython pre-installed!
The OMGS3 ships with the latest version of CircuitPython that supports the ESP32-S3. It also ships with the UF2 bootloader, so you can easily update your OMGS3 with the latest CircuitPython firmware, whenever you desire.
Of course, you can choose from a wonderful array of other languages and platforms. Explore them all below....
Downloads
Download OMGS3 resources, including the schematic, 3D model, KiCAD footprint and more.
GitHub
The Unexpected Maker ESP32-S3 GitHub repository includes:
- 3D STEP files for OMGS3, its carrier and OMGUSB
- Pinout reference card for OMGS3
- KiCAD footprint for OMGS3
- Helper libraries for Arduino and CircuitPython shipping files
Certification
OMGS3 ships uncertified. If you use a OMGS3 on a project that requires certification, you’ll be required to also certify the WiFi and Bluetooth radios as part of your final product.
Links to code and documentation
Documentation (unexpectedmaker.com)
Product HS Code: 8542310070
Shipping policy
All products purchased from this store ship directly from me here in Melbourne, Australia. Orders are processed daily and usually go out within a few days! I'm currently unable to ship to Germany, Denmark, or Sweden, but I am doing my best to work with Australia Post and Zonos about this issue; sorry for any inconvenience. Finally, postage rates suck, and they keep going up; sorry :(
OMGS3 - Just 25 x 10mm in size!
Sold by Unexpected Maker
$18.00
No tax for United States [change]
Stock available: 50
Volume discount | |
2+ items | $17.74 |
4+ items | $17.47 |
10+ items | $16.94 |
