This product was designed by Troy Schrapel (visrealm).
By buying this product you support original hardware creators.
PICO9918 no-cut A/V kit for the Texas Instruments TI-99/4A
PICO9918 No-cut Kit (TI-99/4A)
Sold by Troy Schrapel (visrealm)
$22.00
No tax for United States [change]
This item is currently out of stock.
Sign up to get notified when this product is back in stock.What is it?
Allows you to add the A/V connectors of the PICO9918 to your TI-99/4A without cutting the case.
Designed to replace the existing 5 or 6 pin A/V DIN connector of your TI-99/4A with a custom PCB which includes the original DIN connector in addition to new VGA and audio connectors.
Note: If you order just the PCB or the kit, I will pre-solder the JST or FFC connector for you. The JST connector is also epoxied to the PCB.
Important: Installation requires you to desolder and remove your existing A/V DIN connector from your TI-99/4A PCB. If you're not comfortable doing this, I suggest skipping this mod.
Enclosure
The enclosure provides the stability. Without it, the entire mod PCB is only held in place with the soldered connection to the original TI-99/4A DIN socket.
When selecting an enclosure, be sure to select the correct color for your system as the design of the retaining fins is slightly different between black and beige systems. If you'd prefer to print your own enclosure, the STLs are available in the PICO9918 GitHub repository
PICO9918
This product requires a PICO9918 or PICO9918 PRO VDP replacement (not included).
What do you get?
- 1x PICO9918 no-cut PCB
- FFC or JST connector pre-soldered
For the kit and assembled versions, you will also receive:
- 1x Riser block with pin headers pre-installed
- 1x VGA connector
- 1x White RCA connector
- 1x Red RCA connector
- 1x 3-pin header + jumper
- 1x FFC or JST cable
Links to code and documentation
Product HS Code: 850490
Shipping policy
All orders are usually shipped with tracking within 2 business days.
US customers please note import tariffs and associated fees will be collected during checkout. You will not need to pay any extra upon arrival.
UK customers please note VAT will not be collected and orders with items totalling under £135 (approx. €150) should not attract any import duties.
EU customers please note VAT will be collected and paid for all orders. You should not need to pay any extra upon arrival, however extra charges do apply when the items total over €150.
If the store is showing shipping unavailable to your location, please reach out and I will add a shipping rate for you.
