Description

The IS3730 is an Art-Net receiver chip. It connects to Ethernet to receive Art-Net data and provides an SPI interface for your microcontroller to read the DMX data. This chip handles all the Ethernet protocol complexity and delivers clean, ready-to-use DMX data over SPI.

Art-Net™ Designed by and Copyright Artistic Licence Engineering Ltd.

How Does It Work?

The chip provides two interfaces:

• An SPI interface for your microcontroller, FPGA, Arduino, etc.
  ➜ This is where your system reads the DMX data.

• A RMII interface to connect your preferred Ethernet PHY transceiver chip, like the LAN8720.
  ➜ This is where the chip acces the ethernet to connect with the Art-Net Controller.

Default Chip Settings

Art-Net Settings:

• IP: DHCP

Advantages and Features

Firmware Advantages

• 🛠️ Forget about Art-Net protocol handling: No need to deal with Ethernet

• ❌ No libraries needed: Just use standard SPI functions

• ⚡ Perfect for heavily loaded CPUs or ISR-heavy microcontrollers

• 📝 Arduino, STM32, and Raspberry Pi examples available

• 🧪 Evaluation board available to make some tests in Arduino/Nucleo and Raspberry Pi form factor

• ⏱️ Save firmware engineering time

Hardware Advantages

• 🔌 Save pins on your microcontroller, as it uses SPI: a shared interface

• 🧘 Reduce the CPU load of your microcontroller

• 💾 Reduce Flash and RAM memory footprint

• ⚙️ Save microcontroller resources

• 🗂️ Schematic design examples available

Compatibility Advantages

• 🏎️ Supports SPI speeds up-to 30 MHz

• 🖥️ Ideal for FPGA designs

Production Advantages

• 🧷 Easy-to-solder LQFP package

• 📦 Reels available for pick-and-place machines

Commercial Advantages

• 🚀 Speeds up development

• ⚙️ Faster prototyping

• 🏁 Shorter time-to-market

Need an Evaluation Board?

• For Arduino and STM32 Nucleo Boards: Kappa3730Ard is an Arduino-form-factor evaluation board that lets you prototype and experiment with the Art-Net chip IS3730.

• For Raspberry Pi and other single board computers: The Kappa4310Rasp is a Raspberry Pi-form-factor evaluation board that lets you prototype and experiment with the Art-Net chip IS3730.

Pick'n'Place

📦 Reels available at lower prices for high-volume orders. Contact us.

Questions?

💬 Contact us anytime for support.
